Mark4 10-Inch Long Range FPV Drone - 2.5kg Payload Capacity

Unlock extreme long-range capabilities and heavy-lift performance with the Mark4 10-inch FPV drone. Engineered for professional applications requiring extended flight times and substantial payload capacity, this powerhouse quad handles everything from cinema cameras to delivery missions.

Heavy Lift Performance

• 2.5kg Payload Capacity - Carry GoPros, cinema cameras, LiDAR sensors, or delivery packages
• 10-Inch Propellers - Maximum efficiency and thrust for heavy loads
• High-Torque 3110 Motors - Powerful brushless motors designed for large props and heavy lifting
• Reinforced Frame - Heavy-duty carbon fiber construction withstands demanding missions
• Extended Flight Times - 20-35 minutes depending on payload and battery configuration

Professional-Grade Components

• F405 Flight Controller - Reliable F4 processor with proven performance
• 55A 4-in-1 ESC - High-current capacity for demanding motors and payloads
• ELRS 2.4GHz Receiver - Long-range control with ExpressLRS technology
• 5.8GHz 2.5W VTX - Powerful video transmitter for extended range FPV
• GPS Module - Position hold, return-to-home, and waypoint navigation

Technical Specifications

• Frame Size: 10-inch class (450-500mm wheelbase)
• Flight Controller: F405 with integrated OSD
• ESC: 55A 4-in-1 BLHeli_32 (supports 6S-8S)
• Motors: 3110 900KV brushless (4 pieces)
• Propellers: 10-inch (various pitch options available)
• Video Transmitter: 5.8GHz 2.5W (analog)
• Receiver: ELRS 2.4GHz long-range
• Battery Support: 6S-8S LiPo (XT60 or XT90 connector)
• Recommended Battery: 6S 5000-8000mAh or 8S 4000-6000mAh
• Payload Capacity: Up to 2.5kg (5.5 lbs)
• Flight Time: 20-35 minutes (varies with payload and battery)
• Weight: ~1.2kg (without battery or payload)
• Max Takeoff Weight: ~4kg

Long-Range Capabilities

• ExpressLRS Control - 10km+ control range with ELRS 2.4GHz
• 2.5W Video Transmission - Extended FPV range up to 5-8km
• GPS Navigation - Autonomous waypoint missions and return-to-home
• Efficient Power System - Optimized for maximum flight time and range
• Telemetry Integration - Real-time battery, GPS, and flight data

Build Configurations Available

Multiple options to suit your needs:

• Analog 5.8G 2.5W - Traditional FPV with powerful video transmitter
• Digital HD Options - DJI O3 or HDZero compatibility (select variants)
• ELRS 2.4GHz - Long-range control system included
• TBS Crossfire - Alternative long-range control option

Professional Applications

• Aerial Cinematography - Carry GoPro, action cameras, or small cinema cameras
• Surveying & Mapping - Mount LiDAR, multispectral, or thermal cameras
• Delivery & Logistics - Transport packages up to 2.5kg
• Search & Rescue - Extended flight times for large area coverage
• Agricultural Monitoring - Carry specialized sensors and cameras
• Long-Range Exploration - Multi-kilometer missions with heavy equipment

What's Included

• Mark4 10-inch carbon fiber frame
• F405 flight controller with GPS module
• 55A 4-in-1 ESC
• 3110 900KV brushless motors (4 pieces)
• 10-inch propellers
• 5.8GHz 2.5W video transmitter (analog builds)
• ELRS 2.4GHz receiver
• All mounting hardware and accessories

What You'll Need

• 6S or 8S LiPo battery (5000-8000mAh recommended)
• FPV goggles (analog or digital depending on build)
• ELRS-compatible radio transmitter
• Battery charger (6S or 8S capable)
• FPV camera (if not included in variant)
• Payload mounting system (for heavy lift applications)

Why Choose Mark4 10-Inch?

The Mark4 10-inch platform is purpose-built for pilots and professionals who need more than a standard racing quad can provide. The 2.5kg payload capacity opens up possibilities for carrying professional cameras, sensors, or delivery packages, while the efficient 10-inch propellers and high-capacity battery support deliver flight times that rival commercial drones at a fraction of the cost.

Whether you're a professional cinematographer needing to carry a GoPro with ND filters and accessories, a surveyor requiring extended flight times with specialized sensors, or an FPV pilot exploring extreme long-range missions, the Mark4 10-inch delivers the performance, reliability, and versatility you need.

Note: This is a high-performance platform requiring advanced piloting skills. Always ensure payload is properly secured and balanced. Comply with all local regulations regarding drone weight and operations.
