640 x 512 50Hz 8000-14000nm Radiometric LWIR FLIR Drone Thermal Camera Core for Animal Observation Contrastech
- Free worldwide shipping
SPECIFICATIONS
Brand Name: CONTRASTECH
Image Sensor: Other SONY Series
Effective MegaPixel: About 1.3MP
Supporting Language: English
Hign-concerned Chemical: None
Expand Microphone: No
Main Processor ( Maximum HD Support): GP2
Built-in Mic: None
Display Screen: No
Certification: CE
Application: Semi-professional
Application: Outdoor Sport Activities
Application: Professional
Display Size: Without Screen
Input/Output: other
Video Resolution: 640x512
Waterproof: No
Operating Temperature[°C]: -40 - 80
Built-in Memory Size: Non
Sensor type: Uncooled VOx Detector
Resolution: 640 x 512
Pixel Size (μm): 12 x 12
Frame Rate: 50 fps
EFL(mm): 4.1mm-45mm
Interface: Type-C/BT.656/BT.1120/MIPI/UVC
Dimension/ Weight: 21x21/8g
Power Input: 3.8VDC / 1.8V / 3.3V
|
Model
|
Resolution
|
Detector Frame Rate
|
Type
|
Dimension
|
Weight
|
|
iVaster50BPLW30M
|
640 x 512
|
50kHz
|
Observation
|
21x21mm
|
8g
|
|
iVaster25BPLWT30M
|
640 x 512
|
25kHz
|
Temperature Measurement
|
21x21mm
|
8g
|
|
Other Models Recommended |
|||||
|
iVaster30BPLW120M
|
1280 x 1024
|
30kHz
|
Observation
|
29x29mm
|
24.5g
|
|
iVaster30BPLWT120M
|
1280 x 1024
|
30kHz
|
Temperature Measurement
|
29x29mm
|
24.5g
|
|
iVaster50BPLW11M-Pro
|
384 x 288
|
50kHz [1]
|
Observation
|
26x26mm
|
20g±3g
|
|
iVaster50BPLWT11M-Pro
|
384 x 288
|
50kHz [1]
|
Temperature Measurement
|
26x26mm
|
20g±3g
|
|
iVaster50BPLW30M-Pro
|
640 x 512
|
50kHz [1]
|
Observation
|
26x26mm
|
20g±3g
|
|
iVaster50BPLWT30M-Pro
|
640 x 512
|
50kHz [1]
|
Temperature Measurement
|
26x26mm
|
20g±3g
|
|
Note [1]:
Detector frame rate 50Hz, video frame rate 50Hz(observation type)/25Hz(temperature measurement type)
|
|||||
|
Sensor Type
|
Uncooled VOx Microbolometer
|
|
Spectral range
|
8~14μm
|
|
Pixel spacing
|
12μm
|
|
NETD
|
≤ 50mK@25℃（≤ 40mk optional）
|
|
Operating temperature
|
-40℃～ +80℃（-20℃～ 60℃ Temperature measurement）
|
|
Focal length
|
4.1mm、6.9mm、9.1mm、13mm、25mm、45mm - 640x512
10mm、19mm、35mm - 1280x1024
|
Datasheet Download
