GEPRC T-Cube18 1.8" Micro Whoop FPV Drone 87mm ELRS Analog/HDZero/O4
As low as $44.16/mo with Affirm
Prequalify now • Pay over time • No hidden fees
- Free US shipping on orders $100+
- Low stock - 3 items left
- Backordered, shipping soon
- Secure Checkout
- 30-Day Money-Back Guarantee
- Fast & Reliable Shipping
Ultra-Lightweight 1.8-Inch Micro Whoop with ELRS - Analog, HDZero & DJI O4 Options
The GEPRC T-Cube18 is a premium 1.8-inch micro whoop FPV quadcopter featuring an 87mm wheelbase, TAKER F411-12A-E AIO flight controller with built-in ELRS 2.4GHz receiver, SPEEDX2 1002 brushless motors, and 1.5mm carbon fiber construction. Weighing just 38-47g, this ultra-lightweight platform is available in four configurations: 1S Analog (RAD Tiny VTX + CADDX ANT), 2S Analog (RAD Tiny VTX + CADDX ANT), 2S HD HDZero (HDZero ECO Bundle), and 2S HD O4 (DJI O4 Air Unit) — choose the system that matches your goggles for the perfect indoor and outdoor micro FPV experience.
Key Features
- 87mm Wheelbase - Ultra-compact 1.8-inch micro whoop
- 38-47g Weight - Featherlight for indoor and outdoor flying
- TAKER F411 AIO - F411 FC + 12A ESC integrated
- Built-in ELRS 2.4GHz - Long-range receiver integrated
- SPEEDX2 1002 Motors - 18000KV (2S) or 25000KV (1S)
- 1.5mm Carbon Fiber Frame - Rigid yet lightweight
- 4 Video Configurations - Analog, HDZero, or DJI O4
- Gemfan 45mm Props - Efficient micro propellers
- 3-5 Min Flight Time - On recommended batteries
- 1S or 2S LiHV - Flexible battery options
- Indoor/Outdoor - Versatile flying environments
- Beginner to Expert - All skill levels welcome
Perfect For
- Indoor FPV flying
- Park and outdoor micro flying
- Beginner FPV training
- Tight-space navigation
- Portable FPV sessions
- Micro drone racing
- Learning freestyle skills
- Travel-friendly FPV
Configuration Options
1. Cube18 1S Analog - $272
- Motor: SPEEDX2 1002 25000KV
- VTX: RAD Tiny 5.8G 400mW
- Camera: CADDX ANT
- Battery Connector: A30
- Recommended Battery: LiHV 1S 530mAh
- Weight: 38g ±1g
- Flight Time: 3-5 minutes
- Best For: Ultra-lightweight 1S analog FPV
2. Cube18 2S Analog - $272
- Motor: SPEEDX2 1002 18000KV
- VTX: RAD Tiny 5.8G 400mW
- Camera: CADDX ANT
- Battery Connector: XT30
- Recommended Battery: LiHV 2S 500mAh
- Weight: 38g ±1g
- Flight Time: 3-5 minutes
- Best For: More power with analog FPV goggles
3. Cube18 2S HD HDZero - $333
- Motor: SPEEDX2 1002 18000KV
- VTX: HDZero ECO Bundle
- Gyro: BMI270
- Battery Connector: XT30
- Recommended Battery: LiHV 2S 380mAh
- Weight: 42.6g ±1g
- Flight Time: 3-5 minutes
- Best For: HD digital FPV with HDZero goggles
4. Cube18 2S HD O4 - $489
- Motor: SPEEDX2 1002 18000KV
- VTX: DJI O4 Air Unit
- Gyro: BMI270
- Battery Connector: XT30
- Recommended Battery: LiHV 2S 380mAh
- Weight: 47.2g ±1g
- Flight Time: 3-5 minutes
- Best For: Premium HD digital FPV with DJI Goggles
Technical Specifications (All Versions)
Frame
- Model: T-Cube18
- Wheelbase: 87mm
- Frame Material: 1.5mm carbon fiber
- Additional Materials: Plastic and metal components
- Configuration: Micro whoop quadcopter
Flight Controller - TAKER F411-12A-E 1-2S AIO
- MCU: STM32F411CEU6
- Gyro: BMI270 (HD versions) / ICM series (Analog)
- ESC: 12A 8-bit integrated
- Voltage: 1-2S LiPo/LiHV
- Receiver: Built-in ELRS 2.4GHz
- Firmware: Betaflight compatible
Propellers
- Size: Gemfan 45mm
- Quantity: 8 propellers included (4 pairs)
- Type: Micro whoop propellers
Performance
- Flight Time: 3-5 minutes (battery and flying style dependent)
- Control Channels: 8 channels
- Remote Distance: 1000m+ (ELRS)
- Charging Time: ~30 minutes
- Skill Level: Beginner to Expert
- Use: Indoor and outdoor
Advanced Features
TAKER F411 AIO Flight Controller
The integrated TAKER F411-12A-E combines STM32F411 MCU, BMI270 gyro, 12A 8-bit ESC, and built-in ELRS 2.4GHz receiver in a single compact board specifically designed for 1-2S micro FPV drones. Betaflight compatible for easy tuning and configuration.
Built-in ELRS 2.4GHz Receiver
Integrated ExpressLRS 2.4GHz receiver provides reliable long-range control up to 1000m+ with ultra-low latency. No external receiver needed, saving weight and simplifying the build while delivering superior range compared to traditional receivers.
SPEEDX2 1002 Brushless Motors
High-efficiency brushless motors in 25000KV (1S) or 18000KV (2S) deliver smooth, responsive performance optimized for micro whoop flying. The compact 1002 size provides excellent power-to-weight ratio for agile indoor maneuvers and stable hovering.
1.5mm Carbon Fiber Frame
Lightweight 1.5mm carbon fiber plate provides optimal rigidity and portability while keeping the total weight under 50g. The stiff frame minimizes vibrations for cleaner video and more precise flight characteristics.
Multiple Video System Options
Choose the video system that matches your existing goggles: RAD Tiny 5.8G 400mW analog VTX with CADDX ANT camera for traditional analog setups, HDZero ECO Bundle for HD digital racing video, or DJI O4 Air Unit for the premium DJI digital FPV experience.
1S and 2S Flexibility
The 1S Analog version uses an A30 connector and 530mAh 1S LiHV for ultra-lightweight flying, while all 2S versions use XT30 connectors with 380-500mAh 2S LiHV batteries for more power and performance. Both configurations deliver 3-5 minute flight times.
Choosing Your Configuration
- Have analog goggles? Choose 1S Analog or 2S Analog ($272)
- Have HDZero goggles? Choose 2S HD HDZero ($333)
- Have DJI Goggles? Choose 2S HD O4 ($489)
- Want lightest possible? Choose 1S Analog (38g)
- Want most power? Choose 2S versions
- Want best video quality? Choose 2S HD O4
What's Included
- 1× GEPRC T-Cube18 quadcopter (fully assembled)
- TAKER F411-12A-E AIO flight controller (pre-installed)
- SPEEDX2 1002 brushless motors (4×)
- VTX system (RAD Tiny / HDZero ECO / O4 Air Unit per config)
- CADDX ANT camera (Analog versions)
- 4× Gemfan 45mm propellers (2 pairs)
- 1× Plum screwdriver
- 1× L-shaped screwdriver 1.5mm
- 8× Rubber bands for battery fixing
- User manual and documentation
What You'll Need
- Battery: 1S LiHV 530mAh (1S Analog) or 2S LiHV 380-500mAh (2S versions)
- Battery charger (1S or 2S LiHV compatible)
- ELRS 2.4GHz radio transmitter
- FPV goggles (analog, HDZero, or DJI compatible per config)
- Spare Gemfan 45mm propellers
Important Notes
- 1.8-inch micro whoop FPV quadcopter
- 87mm wheelbase carbon fiber frame
- Weight: 38-47g depending on configuration
- TAKER F411-12A-E 1-2S AIO flight controller
- Built-in ELRS 2.4GHz receiver
- SPEEDX2 1002 brushless motors (18000KV or 25000KV)
- 12A 8-bit integrated ESC
- Gemfan 45mm propellers
- 4 configurations: 1S Analog, 2S Analog, 2S HDZero, 2S O4
- Flight time: 3-5 minutes
- 1S: A30 connector + 530mAh LiHV recommended
- 2S: XT30 connector + 380-500mAh LiHV recommended
- Battery and charger not included
- ELRS 2.4GHz transmitter required
- FPV goggles required (match to your chosen config)
- Betaflight compatible
- CE certified
- Suitable for ages 14+
- Beginner to expert skill level
- Indoor and outdoor capable
