Axisflying Analog VTX 5.8GHz Max 3W High Power Heat Sink OSD TERK Video Transmitter for FPV RC Long Range Drone 5/7/10inch

Regular price $139.99 Sale price$93.30 Save 33%
/
Shipping calculated at checkout.

Color
  • Free worldwide shipping
  • In stock, ready to ship
  • Backordered, shipping soon

SPECIFICATIONS

Brand Name: AXISFLYING

Hign-concerned Chemical: None

Is Electric: No battery

Material: Metal

Recommend Age: 14+y

Size: 53.79x27.8x20mm

Use: Vehicles & Remote Control Toys

Maximum transmission distance: 5000

Transmission power: 3W

Frame rate: 500

Screen resolution: 600

Model:Axisflying  TERK VTX 5.8G 3W

Size:53.79x27.8x20mm

Output power:25mW/200mW/600mW/1600mW/2500mW/Pit mode

Frequency:5.8G

Channel:72CH

CHANNEL: 48CH / 37CH (US)
POWER LEVEL: PIT-25mW- 500mW- 1000mW- MAX*
INPUT : DC 7-36V ( 6S LiPo )
OUTPUT : DC 5V (Max 500mA)
VIDEO IN : CVBS PAL/NTSC
AUDIO IN: 6. 5M MONO
ANTENNA CONNECTOR : MMCX 50Ω
EXTERNAL CONTROL: Smart Audio
SIZE: H 40mm* W 24mm* D 10. 5mm
WEIGHT:15g (With out cable)
*MAX Power level can provide 2500mW(34dbm) or more power depending on the environment's ability to dissipate heat.
