DroneHub Open Source New Smart Drone 300 350 380 450MM Pixhawk Quadrotor Rack RC Multicopter Multi-Rotor With Landing Gear
- Free worldwide shipping
- In stock, ready to ship
- Backordered, shipping soon
SPECIFICATIONS
Brand Name: ROHDE
For Vehicle Type: Airplanes,Airplanes
Hign-concerned Chemical: None,None
Is Electric: No Battery,No battery
Material: Carbon Fiber,Carbon Fiber
Origin: Mainland China
Quantity: 1 pcs,1 pcs
RC Parts & Accs: AXLE,AXLE
Recommend Age: 14+y
Remote Control Peripherals/Devices: Remote Controller,Remote Controller
Technical parameters: KV1100,KV1100
Tool Supplies: Assembled class,Assembled class
Upgrade Parts/Accessories: Frame,Frame
Use: Vehicles & Remote Control Toys
Drone Frame Assembly Manual & Recommended Components List
Introduction
This manual provides instructions on how to assemble your new drone frame and recommends compatible components such as motors, electronic speed controllers (ESCs), and propellers.
Package Contents
Carbon fiber drone frame (300/350/380/450mm arm span)
Landing gear
Mounting screws and accessories
Assembly Instructions
-
Motor Mounting
Attach the motors to each corner of the drone frame using the mounting screws provided.
Ensure that the motor direction is correct: front-left, back-left, front-right, and back-right.
-
Electronic Speed Controller (ESC) Mounting
Mount the ESCs near the motors, ensuring they are securely attached to the drone frame.
-
Battery Mounting
Securely attach the battery to the bottom of the drone frame using the designated mounting points.
-
Flight Controller Mounting
Mount the flight controller in the center of the drone frame, making sure it is level and secure.
-
Landing Gear Installation
Install the landing gear onto the drone frame according to the manufacturer's instructions.
-
Propeller Mounting
Attach the recommended propellers to the motors, following the proper direction: CW for front motors and CCW for rear motors.
Recommended Components List
Motors: 2212 (e.g., T-Motor, EMAX, or similar)
Electronic Speed Controllers (ESCs): 30A (e.g., Simonk firmware)
Propellers: 6/7/810-inch (e.g., HQProp, Gemfan, or similar)
Safety Precaution
Always wear protective goggles when working with drones and their components. Keep fingers and other body parts away from spinning propellers during assembly and operation.
Assembly Tips
Make sure all connections are secure and tight before testing the drone.
Balance the weight distribution by placing heavier components closer to the center of the drone.
Calibrate your ESCs and flight controller according to the respective manuals.
Flight Test
After completing the assembly, perform a series of tests to ensure everything works correctly:
Power up the drone without props to check for any issues.
Perform a bench test with props installed but no throttle applied to verify motor directions.
Gradually increase throttle while holding the drone down to confirm motor rotation and stability.
Once satisfied with the results, proceed to hover and fly the drone outdoors.
Remember to always follow local regulations and guidelines for drone flying.
Conclusion
Congratulations! You have successfully assembled your drone frame and equipped it with recommended components. Enjoy your aerial adventures responsibly and safely!
