SPECIFICATIONS

Brand Name: Auloda

Hign-concerned Chemical: None

Is Electric: No battery

Origin: Mainland China

Material: Metal

Recommend Age: 14+y

RC Parts & Accs: Transmitters

For Vehicle Type: Helicopters

Use: Vehicles & Remote Control Toys

Certification: CE

Upgrade Parts/Accessories: Frame

Remote Control Peripherals/Devices: ESC

Tool Supplies: Assembled class

Quantity: 1 pcs

Model Number: GEPRC MATEN 3.3G VRX/MATEN 3.3G 3W VTX PRO

Four-wheel Drive Attributes: Assemblage

Wheelbase: Bottom Plate

GEPRC MATEN 3.3G VRX with 3.3G Signal Alarmer Specifications

Model: GEPRC MATEN 3.3G VRX with 3.3G Signal Alarmer

Dimension: 52.3×87.5×14.7mm

Frequency: 3083-3480MHz

Channels: 40CH

Input Voltage: DC12-36V(3-8S Battery)

Antenna Connector: SMA

Sensitivity: -98dBm

Modes: VRX Mode, SCAN Mode

Video Connector: 3.5mm coaxial

Power Input: DC3.5mm/1.35mm

Mounting Hole: 1/4″ threaded hole

Weight: 69g

GEPRC MATEN 3.3G VRX Frequency Bands

A:3083，3114，3145，3176，3207，3238，3269，3300

B:3215，3235，3255，3275，3295，3315，3335，3355

C:3170，3190，3210，3230，3250，3270，3290，3310

D:3320，3345，3370，3395，3420，3445，3470，3495

E:3310，3330，3355，3380，3405，3430，3455，3480

GEPRC MATEN 3.3G VRX Instructions

VRX Mode: Switch to SCAN mode,press the BAND button to cycle through frequency bands, and the CHAN button to change channels. Hold either button to activate auto-scan, which will lock onto the channel with the strongest signal.

SCAN Mode: Switch to SCAN mode to automatically scan all available channels. The strongest signal will be displayed, and a beeper will sound, increasing in speed as the signal strength increases.

GEPRC MATEN 3.3G VRX Includes

1 x MATEN 3.3G VRX with 3.3G Signal Alarmer

1 x Power supply cable

1 x Video signal cable

1 x User manual
