SPECIFICATIONS
Brand Name: ZIYOUHU
Origin: Mainland China
Field of View: 13.8X 10.4 / 7.5X5.7
Prism Description: BAK4
Objective Lens Diameter: 19mm / 35mm
Magnification: Digital Zoom 2X, 4X
Material: Metal
Type: Monocular
Origin: Mainland China
Pixel: 384X288
Focus: 19mm/F1.0 / 35mm
Crosshair Reticle: 10 Types adjustment
Image transmission: WiFi real-time image transmission, photography, and video.
Installation interface: Three standard fixing screw holes, Mounting brackets
Eyepiece diameter: Display Screen
Water Resistance Level: IPX6
Lens Coating Description: FMC
Focus Type: CENTRAL
Model Number: XT19-384 , XT19L-384 , XT35-384, XT35L-384
Product Name: Thermal Imaging Scope for Hunting Searching
Suitable: Optical Sighting Observation Searching Thermal Detection
Palette: White hot , black hot, iron red, red hot, forests.
Laser rangefinder: can be extended (optional), ranging from 10 to 1000m
Extenal: Support Connect Handheld Screen ( Not include )
Thermal Imaging Scope with LRF Laser Ranging, WIFI App Image Video Records, Long Range Hot Detection Searching Heat Monocular
◆384*288 Pixels.
◆OLED (1440*1080), a High-performance display.
◆1000m accurate laser distance measurement.
◆Equipped with electronic compass and motion sensors.
◆Compact and lightweight, easy to carry around.
◆Multiple cross-hatching and customisable memory calibration parameters can be set .
◆With the latest Lison II details enhancement algorithm for a more clear picture.
◆WIFI transmission of images and built-in video and photo functions.
◆ Protection class IP66, waterproof
◆Available with universal Picatinny rail
Human (1.8»0.5) m |
750m |
1400m |
1400m |
1900m |
Car (2.3«2.3) m |
1800m |
2200m |
2200m |
3200m |
Recognition distance |
Human (1.82.5) m |
376m |
700m |
700m |
1000m |
Car (23x2.3)m |
910m |
1100m |
1100m |
1600m |
Detection distance
Working temperature |
-30°C- +55°C (-22°F~131°F) |
Storage temperature |
Y0°C~ +70°C |
Max. Recoil Power |
800g/ms |
Capsulation |
IP66 |
Environment parameter
Dimension (mm) |
<165*80*65mm |
<190*80*65mm |
<190*80*65mm |
S200*80*65mm |
Weight (g) |
S470g |
<520g |
<525g |
S570g |
Physical characteristic
Data interface |
Type-C |
Installation interface |
Three standard fixing screw holes, and different optional mounting brackets |
Interface
Battery Type |
Single standard 26500 rechargeable lithium battery, replaceable. |
Battery working time |
>5h |
Charging method |
Support online charging |
External power supply |
DC6V/2A |
Power system
Memory |
32GB |
Photos |
support |
Video |
support |
Image storage
Frame Rate |
50Hz |
Image Correction |
auto/manual |
E-zoom |
2x.4x |
Hot spot tracking |
support |
Cross Reticle |
support |
Palette |
White heat, black heat, iron red(red heatfforests. |
Image transmission |
WiFi real-time image transmission, photography, and video. |
Image performance
Eyepiece Parameter |
40mm |
Magnification |
1.77x-7.08x |
3.26x~13.04x |
1.91x~7.64x |
2.72x~10.88x |
Diopter Adjustment |
-5D-+5D |
Electronic compass/ motion sensor |
support |
Wi-Fi |
support |
Image display
Focus |
19mm/F1.0 |
35mm/F1.0 |
35mm/F1.0 |
50mm/F1.0 |
FOV |
13.8°x10.4° |
7.5°x5.7° |
12.5°x10.0° |
8.8°x7.0° |
Focusing method |
Manual |
Monitor |
OLED, 0.39”, 1440x1080 |
IR lens
Type |
VOx |
Pixel |
384x288 |
640x512 |
Pixel spacing |
12um |
Wavelength range |
8 〜14um |
NETD |
<35mk |
Detector
Items |
Technical parameter |
TX19-384 |
TX35-384 |
TX35-640 |
TX50・640 |
